QuazIR
QuazIR HD+
- 1280 x 1024 px Resolution
- 720p & 1080p Display Formats
- Options of cold shields available
- Stirling Cooler type
- f/2.3 lenses with fixed focal length of 12, 25, 50, 100 mm
- f/4.0 lens with 45-450 mm continuous zoom / others available on request
- Input power of +12 VDC Nominal
- 1 lb without optic
- Size varies based on configuration
- Operating Temperature: -40°F to 160°F
QuazIR LR SD
- 640 x 512 px Resolution
- 480i or 480p Display formats
- 77°K Detector Operating Temperature
- Cold shield available
- Power supply +12 VDC Nominal or +24 VDC Optional
- 2 lb of weight (with out lens)
- 5.5 in (l) x 2.85 in (h) x 2.5 in (w) (Tyipcal without lens)
- Operating Temperature: -40°F to 149°F
- Various Optics available.
QuazIR LR HD
- 1280 x 1024 px Resolution
- 720p or 1080p Display formats
- 77°K Detector Operating Temperature
- Cold shield available
- Power supply +12 VDC Nominal or +24 VDC Optional
- 2 lb of weight (with out lens)
- 5.5 in (l) x 2.85 in (h) x 2.5 in (w) (Tyipcal without lens)
- Operating Temperature: -40°F to 149°F
- Various Optics available.
QuazIR SI 320
- 320 x 256 px Resolution
- 480i or 480p Display formats
- 77°K Detector Operating Temperature
- Cold shield available
- Power supply +12 VDC Nominal or +24 VDC Optional
- 2 lb of weight (with out lens)
- 5.5 in (l) x 2.85 in (h) x 2.5 in (w) (Tyipcal without lens)
- Operating Temperature: -40°F to 149°F
- Various Optics available.
QuazIR SI SD
- 640 x 512 px Resolution
- 480i or 480p Display formats
- 77°K Detector Operating Temperature
- Cold shield available
- Power supply +12 VDC Nominal or +24 VDC Optional
- 2 lb of weight (with out lens)
- 5.5 in (l) x 2.85 in (h) x 2.5 in (w) (Tyipcal without lens)
- Operating Temperature: -40°F to 149°F
- Various Optics available.
